Hobbywing BEC / UBEC V2 10A 2-6S Waterproof Voltage Regulator

Hobbywing BEC / UBEC V2 10A 2-6S Waterproof Voltage Regulator

RPP Price: $24.99

STOCK STATUS:
 In Stock!

Free Shipping
Part Number: HWI30603003
Qty:

Description

The UBEC uses an efficient DC-DC regulator chip with a conversion efficiency of more than 90%. The all-metal housing is designed to help dissipate heat and reduce electromagnetic interference. The UBEC output voltage is adjustable in three stages (6.0/7.4/8.4 V) with a continuous current of 10A and a maximum of 15A. The voltage specifications allow the use of a wide range of servos and electrical equipment such as lights, winches, wipers and etc. At the same time, the UBEC is equipped with overcurrent protection, output short-circuits protection, overheat protection, and IP67 waterproof dust design, and can be widely used on crawlers, trucks, and other electric models as well.

Specifications:
Model：UBEC 10A-Car
Input voltage：2-6s lithium batteries
Output voltage：6.0 / 7.4 / 8.4 V (3 options adjustable)
Output current：Continuous 10A，Instantaneous 15A
Measurement：45*20*16.2mm
Weight ：34g（including wires）

-It adopted the advanced DC-DC regulator chip with conversion efficiency exceeds 90%;
-3 options for the output voltage, applicable for all kinds of receivers/gyros/servos, etc.
-It owns BEC shoot-through protection, which prevents the input voltage from directly flowing to the output end and causing damages to receivers, servos, and other electronic devices;
-It featured other protections like over-current protection, short-circuit protection (at the output end) and thermal protection make the use more safe and reliable;
-It has one status LED, which lights up when the output voltage is within the normal range;
-The external switch can turn on/off the UBEC easily;
-Exquisite aluminum case is helpful for heat dissipation & EMI (Electromagnetic Interference) reduction.
