RC4WD Narrow Stamped Steel Wheel Pin Mount 6-Lug (4)

Specifications:
CNC Machined
Billet Aluminum
Black Anodized Finish
OD: 0.91in / 23.0mm
Center Hole OD: 0.16in / 4.2mm
Width: 0.18in / 4.5mm
Each Weight: 0.10oz / 2.9g

Shown installed with TRO 1.7" Stamped Steel Beadlock Wheels (Black/Chrome) for example (Not Included)


This hub will narrow the offset 2.1mm over the stock wheel hub.

What's Included:
4x Wheel Hex Hub Brake Discs
24x M2.5 x 10mm Steel Flat Head Socket Cap Screws
24x Regular M2.5 Black Nuts

Replacement Hardware:
M2.5 x 10mm Steel Flat Head Socket Cap Screws
Regular M2.5 Black Nuts (Z-S0303)

Optional Parts:
Yota II Ultimate Scale Cast Axle (Center Rear) (Z-A0010)
Yota Ultimate Scale Cast Axle (Front) (Z-A0058)
Yota Ultimate Scale Cast Straight Axle (Rear) (Z-A0061)
Yota II Ultimate Scale Cast Axle (Front) (Z-A0080)
Yota II Ultimate Scale Cast Axle (Rear) (Z-A0081)
Yota II Ultimate Scale Cast Axle (Center Front) (Z-A0086)

Notes:
Fits the following 1.7" Wheels: Z-W0225
Fits the following 1.9" Wheels: Z-W0002, Z-W0073, Z-W0074, Z-W0128, Z-W0130
Fits the following 2.2" Wheels: Z-W0141, Z-W0146, Z-W0190
Please note this hub is designed to narrow the offset of our steel wheels. These will not work on Axial SCX10 and SCX10 II axles due to fitment on the axle threads.
Please note these hubs will require a washer or spacer when mounting on Axial Axles due to different depth of the threads.
